Recently updated on December 16th, 2024
How to install internal blower on inflatable arches.
Summary
With the fast-paced world of event marketing, quickly setting up an inflatable arch is vital. This guide presents a straightforward approach to installing the internal blower onto the arch for a seamless process.
Step-by-Step Instructions
Step 1: Preparing Components
- Gather the inflatable arch and the blower assembly components.
- If the hole for the blower is not already cut, follow the next steps.
Step 2: Cutting the Hole (If Necessary)
- Unscrew the plate from the blower assembly.
- Position the plate on the arch where the blower will be placed.
- Trace a circle around the plate using a pen or marker as a guide.
- Cut out the traced circle to create the appropriate hole size.
Step 3: Installing the Blower
- Remove the plate and feed the blower through the hole in the arch.
- Align the blower base with the holes on the arch.
- Secure the blower in place by lining up the holes and reattaching the plate.
Step 4: Securing the Blower
- Use the provided screws to secure the plate tightly to the arch.
- Ensure a snug fit to prevent any air leakage during operation.
Step 5: Final Setup
- Feed the blower cord out through the arch zipper.
- Zip up the arch to enclose the blower assembly securely.
- Plug in the blower to power it up, initiating the inflation process.
